2N3506 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-205AD, TO-39-3 Metal Can
- Description: NPN POWER SILICON TRANSISTORS
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N3506 Specifications:
- MfrPart.: 2N3506
- Mfr: Microchip Technology
- Description: NPN POWER SILICON TRANSISTORS
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 500 mA
- Voltage-CollectorEmitterBreakdown(Max): 40 V
- VceSaturation(Max)@IbIc: 500mV @ 50mA, 500mA
- Current-CollectorCutoff(Max): -
- DCCurrentGain(hFE)(Min)@IcVce: 40 @ 1.5A, 2V
- Power-Max: 1 W
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-205AD, TO-39-3 Metal Can
- 2N3506 Microchip, NPN POWER SILICON TRANSISTORS, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
