2N2325 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Thyristors - SCRs Package/Case: TO-205AD, TO-39-3 Metal Can
- Description: SCR 150V 200UA TO39
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N2325 Specifications:
- MfrPart.: 2N2325
- Mfr: Microchip Technology
- Description: SCR 150V 200UA TO39
- Product Category: Discrete Semiconductor Products~Thyristors - SCRs
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- Voltage-OffState: 150 V
- Voltage-GateTrigger(Vgt)(Max): 800 mV
- Current-GateTrigger(Igt)(Max): 200 µA
- Voltage-OnState(Vtm)(Max): 2.2 V
- Current-OnState(It(AV))(Max): 1.6 A
- Current-OnState(It(RMS))(Max): -
- Current-Hold(Ih)(Max): 2 mA
- Current-OffState(Max): 10 µA
- Current-NonRepSurge5060Hz(Itsm): -
- SCRType: Sensitive Gate
- OperatingTemperature: -65°C ~ 125°C
- MountingType: Through Hole
- Package/Case: TO-205AD, TO-39-3 Metal Can
- 2N2325 Microchip, SCR 150V 200UA TO39, Discrete Semiconductor Products~Thyristors - SCRs
