1N6763 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: TO-254-3, TO-254AA
- Description: RECTIFIER DIODE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
1N6763 Specifications:
- Manufacturer Product Number: 1N6763
- Mfr: Microchip Technology
- Detailed Description: RECTIFIER DIODE
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/642
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 100 V
- Current - Average Rectified (Io): 12A (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.05 V @ 12 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 35 ns
- Current - Reverse Leakage @ Vr: 10 µA @ 100 V
- Capacitance @ Vr, F: 300pF @ 5V, 1MHz
- Mounting Type: Through Hole
- Package / Case: TO-254-3, TO-254AA
- Operating Temperature - Junction: -55°C ~ 175°C
- 1N6763 Microchip, RECTIFIER DIODE, Discrete Semiconductor Products~Diodes - Rectifiers - Single
