1N6760 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-204AL, DO-41, Axial
- Description: DIODE SCHOTTKY 80V 1A DO41
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
1N6760 Specifications:
- Manufacturer Product Number: 1N6760
- Mfr: Microchip Technology
- Detailed Description: DIODE SCHOTTKY 80V 1A DO41
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: -
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 80 V
- Current - Average Rectified (Io): 1A
- Voltage - Forward (Vf) (Max) @ If: 690 mV @ 1 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 100 µA @ 80 V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: DO-204AL, DO-41, Axial
- Operating Temperature - Junction: -65°C ~ 150°C
- 1N6760 Microchip, DIODE SCHOTTKY 80V 1A DO41, Discrete Semiconductor Products~Diodes - Rectifiers - Single
1N6760, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
