1N6391 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-203AA, DO-4, Stud
- Description: SCHOTTKY BARRIER RECTIFIER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
1N6391 Specifications:
- Manufacturer Product Number: 1N6391
- Mfr: Microchip Technology
- Detailed Description: SCHOTTKY BARRIER RECTIFIER
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/553
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 45 V
- Current - Average Rectified (Io): 25A (DC)
- Voltage - Forward (Vf) (Max) @ If: 500 mV @ 5 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 1.5 mA @ 45 V
- Capacitance @ Vr, F: 2000pF @ 5V, 1MHz
- Mounting Type: Stud Mount
- Package / Case: DO-203AA, DO-4, Stud
- Operating Temperature - Junction: -55°C ~ 175°C
- 1N6391 Microchip, SCHOTTKY BARRIER RECTIFIER, Discrete Semiconductor Products~Diodes - Rectifiers - Single
