1N5813R Microchip RECTIFIER DIODE
1N5813R Images
1N5813R Images
1N5813R
  • Manufacturer: Microchip
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-203AA, DO-4, Stud
  • Description: RECTIFIER DIODE
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
1N5813R Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
1N5813R Specifications:
  • Manufacturer Product Number: 1N5813R
  • Mfr: Microchip Technology
  • Detailed Description: RECTIFIER DIODE
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
  • Package: Bulk
  • Series: -
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 75 V
  • Current - Average Rectified (Io): 20A
  • Voltage - Forward (Vf) (Max) @ If: -
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 35 ns
  • Current - Reverse Leakage @ Vr: 10 µA @ 75 V
  • Capacitance @ Vr, F: -
  • Mounting Type: Stud Mount
  • Package / Case: DO-203AA, DO-4, Stud
  • Operating Temperature - Junction: -55°C ~ 175°C
  • 1N5813R Microchip, RECTIFIER DIODE, Discrete Semiconductor Products~Diodes - Rectifiers - Single
