1N5806TR Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: A, Axial
- Description: DIODE GEN PURP 150V 2.5A AXIAL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
1N5806TR Specifications:
- Manufacturer Product Number: 1N5806TR
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Detailed Description: DIODE GEN PURP 150V 2.5A AXIAL
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bag
- Series: -
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 150 V
- Current - Average Rectified (Io): 2.5A
- Voltage - Forward (Vf) (Max) @ If: 875 mV @ 1 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 25 ns
- Current - Reverse Leakage @ Vr: 1 µA @ 150 V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: A, Axial
- Operating Temperature - Junction: -65°C ~ 175°C
- 1N5806TR Microchip, DIODE GEN PURP 150V 2.5A AXIAL, Discrete Semiconductor Products~Diodes - Rectifiers - Single
