1N3903 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-203AB, DO-5, Stud
- Description: DIODE GEN PURP 400V 20A DO5
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
1N3903 Specifications:
- Manufacturer Product Number: 1N3903
- Mfr: Microchip Technology
- Detailed Description: DIODE GEN PURP 400V 20A DO5
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: -
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 400 V
- Current - Average Rectified (Io): 20A
- Voltage - Forward (Vf) (Max) @ If: 1.4 V @ 63 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 200 ns
- Current - Reverse Leakage @ Vr: 50 µA @ 400 V
- Capacitance @ Vr, F: 150pF @ 10V, 1MHz
- Mounting Type: Stud Mount
- Package / Case: DO-203AB, DO-5, Stud
- Operating Temperature - Junction: -65°C ~ 150°C
- 1N3903 Microchip, DIODE GEN PURP 400V 20A DO5, Discrete Semiconductor Products~Diodes - Rectifiers - Single
