1N3891 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-203AA, DO-4, Stud
- Description: FAST RECOVERY RECTIFIER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
1N3891 Specifications:
- Manufacturer Product Number: 1N3891
- Mfr: Microchip Technology
- Detailed Description: FAST RECOVERY RECTIFIER
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/304
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 200 V
- Current - Average Rectified (Io): 12A
- Voltage - Forward (Vf) (Max) @ If: 1.5 V @ 38 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 200 ns
- Current - Reverse Leakage @ Vr: 25 µA @ 50 V
- Capacitance @ Vr, F: 115pF @ 10V, 1MHz
- Mounting Type: Stud Mount
- Package / Case: DO-203AA, DO-4, Stud
- Operating Temperature - Junction: -65°C ~ 175°C
- 1N3891 Microchip, FAST RECOVERY RECTIFIER, Discrete Semiconductor Products~Diodes - Rectifiers - Single
1N3891, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
Microchip Authorized Distributor | NHE is dedicated to providing first-quality, genuine Microchip components.
